Ubiquiti - UB-USW-PRO-24-POE - Switch Gen2 24x1Gbit 2xSFP+

Hersteller:

UBIQUITI Artikelnummer: 802-UB-USW-PRO-24-POE

Ubiquiti - UB-USW-PRO-24-POE - Switch Gen2 24x1Gbit 2xSFP+

GTIN: 817882028349
HAN: UB-USW-PRO-24-POE
Kategorie: SWITCHES

Ubiquiti - UB-USW-PRO-24-POE - Switch Gen2 24x1Gbit 2xSFP+

771,81 €

inkl. USt. , zzgl.

Knapper Lagerbestand
Lieferzeit: 3 - 5 Werktage (AT - Ausland abweichend)

Stk

Bitte beachten Sie das Abnahmeintervall von 1 Stk.

Beschreibung

Hardware
Dimensions	442 x 285 x 44 mm (17.4 x 11.2 x 1.7")
Weight	Without mounting brackets: 4.3 kg (9.5 lb) With mounting brackets: 4.4 kg (9.7 lb)
Enclosure material	SGCC steel
Management interface	Ethernet In-Band
Networking interface	(24) GbE RJ45 ports (2) 1/10G SFP+ ports
PoE interface	(16) PoE/PoE+ (Pins 1, 2+; 3, 6-) (8) 60W PoE++; PoE/PoE+ (Pins 1, 2+; 3, 6-) / PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput	44 Gbps
Switching capacity	88 Gbps
Forwarding rate	65.472 Mpps
Power method	(1) Universal input, 100—240V AC, 50/60 Hz (1) USP-RPS DC input, 52V DC, 7.69A; 11.5V DC, 2.61A
Power supply	AC/DC, internal, 450W
Supported voltage range	100—240V AC
Max. power consumption	50W (Excluding PoE output)
Total available PoE	400W
Max. PoE wattage per port by PSE	PoE+: 32W PoE++: 64W
Voltage range PoE mode	PoE: 44—57V PoE+: 50—57V
ESD/EMP protection	Air: ± 16kV, contact: ± 12kV
LCM display	(1) 1.3" touchscreen
Button	Factory reset
Shock and vibration	ETSI300-019-1.4 Standard
Ambient operating temperature	-5 to 40° C (23 to 104° F)
Ambient operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
Switching Features
Layer 2 features	IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features	DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs
LEDs
System	Status
Ethernet	PoE Speed/link/activity
SFP+	Link/activity
RPS	Status
Application Requirements
UniFi Network	Version 5.10.5 and later

Versandgewicht:

6,25 kg
Artikelgewicht:

4,80 kg
